Wire End Stripping & Twisting Machine

JCW-CS01A

Wire range: 0.1 - 4mm

Stripping length: max 20mm

Rated power: 40W

Power supply: AC 110 - 220V

Dimensions: L 210 x W 125 x H 155 mm

Net weight: 6 kg

Inquire Now

Wire End Stripping Twisting

Fine Wire End Stripping & Twisting Machine

The JCW-CS01A is an electric rotary wire end stripping and twisting machine built specifically for fine-gauge wires.

The operator manually inserts the wire into the working position. The machine completes rotary insulation stripping and strand twisting automatically.

Blade sets are interchangeable; different blades must be fitted for varying wire diameters.

It is a practical, compact solution for small-batch electronic wire and wire harness processing.

Model	JCW-CS01A Wire End Stripping & Twisting Machine
Function	Wire end stripping, Conductor twisting, Quick change of cutter
Raw material	PVC, Teflon, Silicone, Low halogen, Fiberglass, etc
Capacity	0.1 - 4 mm
Stripping length	2 - 20 mm
Rated power	120 W
Power supply	AC 220 V ± 10%, 50 / 60 Hz
Dimensions	L 210 x W 125 x H 155 mm
Weight	6 KG
CE-Conformity	Complies with CE equipment guidelines relative to mechanical and electrical safety and electromagnetic compatibility.
