120D
Cr40 forge steel made H.C, more than 6 months aging treatment
2mm thick hardened layer
Pipeless hydraulic valve-block connection
Stable pressure conduction fits in any workshop
Semi-auto mode achieves accurate crimping
Fully-auto mode enables batch crimping
| Model | Hydraulic Hose Crimping Machine |
| H.C. Material | 3 - 80 mm |
| Conductor cross-section | Forge Steel ( Cr40 ) |
Max.Hydraulic hose | 2”, 4SP ( ID 51MM ) |
Max opening | + 25 mm |
Crimp force | 200 T |
| OEM | Yes |
Die sets | 10 sets |
Open cycle | 4.5 seconds |
Open without dies | 118 mm |
Accessible diameter | 118 mm |
Master die length | 80 mm |
System pressure | 31.5 MPa |
Control | Automatic / Semi-automatic |
Power supply | AC 110 - 480V |
Rated power | 4 KW |
Noise level | 65dB(A) |
Dimensions | L 600 x W 480 x H 690 mm |
| Weight | 220 KG |
