JCW-CST05 Fully Automatic Servo Motorized Wire Crimping Machine

Single wire dual-end stripping to crimping of wires with small cross-sections


High-end crimping machine

The JCW-CST05 is a high-end fully-auto wire stripping and crimping machine. The machine allows prefeeding, cutting, stripping, and crimping of wires in the cross-section range from 0.1 mm² to 2 mm², crimping force is 2 tons ( 20 KN ). Synchronous wire pre-feeder keeps proper wire tension. All parameters such as wire data and crimp data can be saved and retrieved for future use.


High-quality processing and simple operation

The JCW-CST05 is a fully automatic wire processing machine for the toughest requirements. The machine integrates high-quality components, Nidec servo motors, Panasonic PLC, a highly rigid transmission structure, high-speed control system. Production parameters are entered with the 7" WEINVIEW touch screen monitor via the intuitive user interface to reduce training time and minimize entry errors. The JCW-CST05 offers vivid detection functions, wire lack detection, wire knot detection, stripping detection, crimping detection, air pressure detection, etc.


Various peripherals

- Crimping force monitoring ( CFM )

- Wire prefeeder for keeping proper wire tension

- Conveyor belt for stacking finished wire


ModelJCW-CST05 Automatic Servo Motorized Wire Crimping Machine
Function

Wire pre-feeder, Single / Dual-end strip, Single / Dual-end crimp, Cut depth, Pull-off length, Crimp position

Conductor cross-section0.03 - 2 mm² ( AWG 32 - 14 )
Stripping lengthFront Side: 0.2 - 8 mm
Rear Side: 0.1 - 10 mm
Cutting length22 - 99999 mm
Crimping force20 KN ( 2.0 tons )
Cutting depth adjustment0.01mm, max 3.50mm
Production rate3600 pcs/h [ cutting length 50mm, crimp one side ]
Rated power2200 ~ 2500W
Power supplyAC 110 - 220V ± 10%, 50 / 60 Hz
Air supply 0.5 - 0.7 MPa [ Clean and dry air ]
Weight460 KG
Dimensions L 1400 x W 1000 x H 1800mm
Accessory deviceSynchronous wire pre-feeder, paper winder
Optional peripheralWire pre-feeder, CFM, wire stacker
DetectionWire lack, Wire jam, Stripping, Crimping, Air pressure
CE-Conformity

Complies with CE equipment guidelines relative to mechanical and electrical safety and electromagnetic compatibility.
