Servo Model 50mm² Cable Cutter Stripper

JCW-CS05B-50

Powerful cable cutting stripping machine

Freestanding version is optional

Left feeding version is optional

Inquire Now

Servo Motorized Cable Cutting Stripping Machine

Model	JCW-CS05B-50 Servo Model Cable Cutter Stripper
Function	Single wire, Multicore cable, Wire measuring, Cut length, Full stripping, Partial stripping, Mid-stripping, Cut depth, Length correction, Cable rewinding ( optional )
Raw material	PVC, Teflon, Silicone, Low halogen, Fiberglass, etc
Cable range	Max 50 mm²
Cutting length ( L )	0.1 - 999999 mm
Cutting length accuracy	0.002 x L
Stripping length	Front full strip：1- 200mm, partial strip: 1-500m
Stripping length	Rear full strip：1- 80mm，partial strip：1-200mm
Production rate	800-1200 pcs/h
Data library	100 programs
Cutter head	Servo motorized
Multicore cable	Only outer jacket stripping
Display	7" color touchscreen, English / Chinese [ other languages on request ]
Cable feeding	Belt feeding system, 8 rollers
Compatible peripherals	Cable prefeeding machine, robot arm, conveyor belt, cable rewinding machine
Power supply	AC 110 - 220 V ± 10%, 50 / 60 Hz
Air supply	0.4 - 0.7 MPa ( clean and dry air )
Dimensions	L 650 x W 580 x H 460 mm
Weight	70 KG
CE-Conformity	Complies with CE equipment guidelines relative to mechanical and electrical safety and electromagnetic compatibility.
