JCW-2TS Series Servo Motorized Wire Crimping Machine

Fully programmable via color touch screen, 40MM stroke on request

Eay to use

This series of terminal crimping machines use servo motors to ensure high precision and offer huge flexibility. Instead of manual adjustment, the crimp height is settable via touchscreen. The JCW-2TS terminal crimping machine monitors and shows the real crimp height of each crimping, ensuring 100% crimping quality.

This servo motorized terminal crimping machine featured multi-terminal function, it allows continuous crimping same terminal onto wires at different cross-sections with no adjustment on crimping height.

Fast, quiet, and precise crimping

The fully programmable JCW-2TS bench-top press is designed to achieve top crimping quality. The ideal speed for the crimping process can be individually adjusted to match the operator efficiency. The JCW-2TS terminal crimping machine is activated by a foot pedal. This electric terminal crimping machine adopts a servo drive to minimize power consumption and cause low noise.

Each machine comes with power cords suitable for different countries, a foot pedal, a lamp for the working area lighting, and a reel holder bracket.


JCW-2TS Series Servo Motorized Terminal Crimping Machine

FunctionSide-feed terminal, End-feed terminal, Crimp height, Continuous crimping
Crimping force20 KN [ 30 - 500 KN on request ]

30 MM [ 40 MM on request ]

Rated power750 W
ActivationFoot pedal
Power supply
AC 110 - 220 V ± 10%, 50 / 60 Hz
DimensionsL 380 x W 380 x H 800 mm
Weight65 KG

Complies with CE equipment guidelines relative to mechanical and electrical safety and electromagnetic compatibility.
